Design Parameters with Standard Supply:

• L 599 mm / D 26 mm / 1.5 HP Smooth Screw Extruder – suitable for HDPE / PP / LDPE / PS / PET: 1 no.
• Process Control Panel synchronized by one master control: 1 no.

• Material to be processed: Recycled HDPE / PP / LDPE / PS Grinded Scrap
• Size to be manufactured: Up to 5 ft Length
• Screw RPM: 70 RPM
• Screw Size: Length 599 mm, Outer Diameter 26 mm
• Barrel Size: Length 620 mm, Outer Diameter 34 mm, Inner Diameter 26 mm
• Max. Extrusion Output: Depends on material used
• Advanced extrusion control with optimized workflow to fill moulds
• Total Connected Load: Approx. 5 kW

• Barrel Type: Smooth Feed Barrier type, high-speed design
• Screw Barrel Material: EN 41B Nitro alloy steel, gas nitride treated
• Gear Reducer: Helical gearbox with heavy-duty thrust bearing
• Main Motor: AC Motor 2 HP
• Barrel Heating Zones: 2 heating zones (ceramic band heater with energy saving)
• Barrel Heating Loads: 3 kW
• Hopper Loader: MS fabricated hopper
• Structure: MS fabricated heavy-duty structure made from angles and channels, covered with sheet metal

• Temperature Controllers: PID controller with autotuning & dual display
• MCB: Reputed make MCB inline for every heating zone supply
• Other Electrical Outfits: Amp meter, contactors, synchronization card, inline choke, and standard cord wiring with PVC duct framing

• We offer customization as per customer needs.
• International shipping available*.
