Design Parameters with Standard Supply:

• 2/3 HP Single Motor
• Gearbox: NMRV90 1:30
• Shredder Body
• Supporting Systems

• Shaft: Single-axis shaft made of EN8 with Hardox blades
• Dimensions: 600 × 300 × 1200 mm
• Power: 1.5 kW
• Voltage Options: 430V / 380V / 220V / 110V (3-Phase or 1-Phase)
• Electrical Panel: Customizable as per your country’s input
• Current: 6 A
• Max Production Output: Depends on material type
• Main Motor: AC Motor 2 HP 3P
• Hopper Loader: MS Fabricated Hopper
• Structure: MS heavy-duty frame made from angles and channels, enclosed with sheet metal.
